Merlin Commander Elite MS105MYQ

FOR PICK-UP ONLY

This Product Includes:

• 2 x  Four Button Remote Control (Security+ 2.0 & Security+) (E970M)
• Four Button Wireless Wall Mount Remote Control  (Security+ 2.0) (E148M)

PRODUCT FEATURES:

• 1 Year back to base Manufacturer Warranty if you Install it yourself.
• 7 Year Manufacturer's Warranty if it's installed by a Professional.

Product Features:

• MYQ COMPATIBLE TECHNOLOGY ¹ lets users create schedules, monitor, receive alerts and control the garage door opener away from home.
• SOFT-START AND SOFT-STOP for smooth operation.
• 7-YEAR WARRANTY
• QUIET DC MOTOR eliminates noise and vibrations through the ceiling and provides smooth operation.
• BATTERY BACKUP ensures access even when the power is out.²
• HEAVY-LIFTING POWER operates doors up to 150 kgs.
• SECURITY+ 2.0® sends a new code with every remote click.
• PREMIUM AUTOMATIC SAFETY REVERSE function will allow your garage door to stop and reverse automatically if obstructed going down or stop going up.
• TIMER-TO-CLOSE automatically closes the door after a pre-set amount of time.³
• IMPROVED TRANSMITTER RANGE has up to 18% better range meaning you can start opening your garage door sooner.⁴
• AUTOMATIC FORCE SENSING monitors and adjusts the force needed to open your garage with each operation.
• MANUAL RELEASE CORD allows you to open your garage door whenever needed.

¹ Additional purchase of Merlin myQ Gateway and Safety IR Beams accessories is required to enable myQ functionality. myQ will only work with Sectional Garage Doors.
² Additional purchases of Merlin Battery Backup accessory are required to enable Battery Backup functionality.
³ Safety IR Beams must be installed to enable the use of Timer-to-Close. See User Guide for additional information. Smartphones are not included.
⁴ When compared to other available Merlin products.

Specifications:

General

• 24V DC motor with thermal overload protection
• Input voltage: 240V AC
• Rated door area up to 20m²
• Max door weight: up to 150kg
• Max peak pulling force: 1000 N
• C-rail with belt drive
• 433.92, 433.30, 434.54 MHz AM radio with Chamberlain Security + 2.0 rolling code technology
• Up to 64 memory registers
• Courtesy light: Powerful LED Lighting
• Min headroom required: 30mm

• Maximum lifting under spring tension = 20kg
• Suitable for steel and timber spring balanced doors

• Door opening time: 18 seconds
• Door closing time: 22 seconds
• Based on a 2.4m high door

• Door height: 3.5m
• Door width: 5.7m
• Double dwelling

Safety Features:

Premium Automatic Safety Reverse

• With its automatic safety function your garage door will stop and reverse automatically if obstructed going down or stop going up.

Automatic Force Sensing

• Equipped with automatic force sensing, with each operation the garage door opener monitors and adjusts the force needed to open your garage door.

Manual Release

• In case of power failure you can simply activate the manual release to open your garage door.

WARNING!

The product includes wireless transmitters and wall controls that contain coin/button cell batteries.
Keep wireless devices and batteries away from children.
The battery can cause severe or fatal injuries in 2 hours or less if swallowed or placed inside any part of the body.
Seek immediate medical attention if it is suspected that a coin/button cell battery has been swallowed or placed inside any part of the body.
